USED 2021 Chevrolet Express Commercial Cutaway 3500 Van 159"
Vin: 1GB0GSF74M1309258
Stock #: 446348
Mileage: 44,576
Price:
$32,990
Year:
2021
Make:
Chevrolet
Model:
Express Commercial Cutaway
Body Style:
3500 Van 159"
Exterior Color:
Summit White
Interior Color:
GRAY
Engine:
V8 6.6 Liter
Transmission:
Automatic 6-Spd HD w/Overdrive
Mileage:
44,576
Stock #:
446348
VIN:
1GB0GSF74M1309258
Vehicle Comments
CHEVROLET EXPRESS CARGO VAN 14FT MORGAN BOX.
- Verified Equipment
- Standard Features
- Tech Specs
- Factory Equipment
- Consumer Information
- Factory Options
- SUMMIT WHITE
- ENGINE, 6.6L V8with Direct Injection and Variable Valve Timing, gasoline, (401 hp [299 kW] @ 5200 rpm, 464 lb-ft of torque [629 N-m] @ 4000 rpm)
- Selected Equipment
- V8 6.6 Liter
- Automatic 6-Spd HD w/Overdrive
- 14' x 8' Box
- ABS (4-Wheel)
- Air Bags: Dual Front
- Power Steering
- RWD
- Single Rear Wheels
- Towing Pkg
Please Note: The included equipment is based on the dealership's bookout process and manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Safety
- Daytime Running Lamps
- StabiliTrak, traction assistance and vehicle stability enhancement system
- Brake/transmission shift interlock for automatic transmissions
- Hill Start Assist
- Tire Pressure Monitor System (does not monitor spare tires) (Required with (C4M) 9900 lbs. (4490 kg) GVWR and (R04) single rear 4 - 16" x 6.5" (40.6 cm x 16.5 cm) wheels.)
- Exterior
- Wheel configuration, rear, single (Not available with (C7N) 12,300 lbs. (5579 kg.) GVWR.)
- Bumper, front painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package is ordered.)
- Grille, Black composite (Not available with (ZR7) Chrome Appearance Package.)
- Headlamps, dual halogen composite
- Flasher, heavy duty light emitting diode (LED)
- Glass, Solar-Ray light-tinted, all windows
- Mirrors, outside delete (Not available with (5Q7) Upfitter option Blank Sail Panel Delete when ordered with (YF2) Ambulance Package.)
- Wipers, front intermittent wet-arm with pulse washers
- License plate kit, front
- Interior
- Cup holders, 3 on the engine console cover
- Floor covering, Black rubberized-vinyl front
- Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature and oil pressure
- Driver Information Center includes fuel range, average speed, oil life, fuel used, ice warning, engine hours, average fuel economy, tachometer and maintenance reminders
- Warning tones, headlamp on and key-in-ignition
- Oil life monitor
- Theft-deterrent system, vehicle, PASS-Key III
- Heater and defogger with front and side window defoggers
- Headliner, cloth, over driver and passenger
- Visors, driver and front passenger, cloth, padded
- Assist handles, driver and right-front passenger
- Lighting, interior with dome light and door handle-activated switches
- Chevrolet Connected Access capable (Included and only available with (UE1) OnStar. Subject to terms. See onstar.com or dealer for details.)
- Mechanical
- Engine, 6.6L V8 with Direct Injection and Variable Valve Timing, gasoline, (401 hp [299 kW] @ 5200 rpm, 464 lb-ft of torque [629 N-m] @ 4000 rpm) (Includes external oil cooler. Requires (MYD) 6-speed heavy-duty automatic transmission. Reference the Engine/Axle page for availability.)
- Rear axle, 3.42 ratio (Requires (R04) single rear wheel configuration.)
- Body, standard
- GVWR, 9900 lbs. (4490 kg) (Includes (R04) single rear wheel configuration. Not available with (R05) dual rear wheel combination. Reference the Engine/Axle page for availability.)
- Tow/haul mode selector, instrument panel-mounted
- Rear wheel drive
- Cooling, external engine oil cooler
- Battery, 600 cold-cranking amps maintenance-free with rundown protection and retained accessory power
- Alternator, 150 amps
- Frame, ladder-type
- Incomplete vehicle certification
- Suspension, front independent with coil springs and stabilizer bar
- Suspension, rear hypoid drive axle with multi-leaf springs
- Steering, power
- Brakes, 4-wheel antilock, 4-wheel disc
- Fuel tank capacity, mid-frame and approximately 32 gallons (121.1L)
- Exhaust, aluminized stainless-steel muffler and tailpipe
- Entertainment
- 4G LTE Wi-Fi Hotspot capable (Included and only available with (UE1) OnStar. Terms and limitations apply. See onstar.com or dealer for details.)
Please Note: These features are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Chassis
- Frame
- Frame Type: Ladder-type
- Tires
- Revolutions/Mile @ 45 mph - Front: N/A Rev/Mile
- Revolutions/Mile @ 45 mph - Rear: N/A Rev/Mile
- Brakes
- Brake Type: Pwr
- Brake ABS System: 4-wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 12.8 x 1.5 in
- Wheels
- Front Wheel Size: 16 x 6.5 in
- Rear Wheel Size: 16 x 6.5 in
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Steering
- Steering Type: Pwr
- Steering Ratio (:1), On Center: 17.2
- Steering Ratio (:1), At Lock: - TBD -
- Turning Diameter - Curb to Curb: 54.5 ft
- Turning Diameter - Wall to Wall: N/A ft
- Fuel Tank
- Fuel Tank Location: Mid-frame
- Suspension
- Suspension Type - Front: Indep Coil Spring
- Suspension Type - Rear: Multi-leaf
- Spring Capacity - Front: 4100 lbs
- Spring Capacity - Rear: 6084 lbs
- Axle Type - Front: Independent
- Axle Type - Rear: Full-Floating
- Axle Capacity - Front: 4100 lbs
- Axle Capacity - Rear: 6084 lbs
- Shock Absorber Diameter - Front: 35.0 mm
- Shock Absorber Diameter - Rear: 35.0 mm
- Stabilizer Bar Diameter - Front: 1.38 in
- Weight Information
- Gross Axle Wt Rating - Front: 4100 lbs
- Gross Axle Wt Rating - Rear: 6084 lbs
- Curb Weight - Front: 3203 lbs
- Curb Weight - Rear: 1762 lbs
- Frame
- Vehicle
- Vehicle
- Model Group: Express Cutaway
- Vehicle Segment: Chassis
- Vehicle Type: Chassis
- Body Cab Style: Chassis
- Country of Origin: United States Active Incomplete Vehicle
- Vehicle
- Dimensions
- Exterior Dimensions
- Wheelbase: 159 in
- Length, Overall: 267.15 in
- Height, Overall: 83.78 in
- Overhang, Front: 39.7 in
- Front Bumper to Back of Cab: 98.7 in
- Cab to Axle: 100 in
- Cab to End of Frame: 168.45 in
- Ground to Top of Frame: 30.08 in
- Frame Width, Rear: 42 in
- Ground Clearance, Front: 9.3 in
- Ground Clearance, Rear: 8.35 in
- Interior Dimensions
- Front Head Room: 40.85 in
- Front Leg Room: 41.35 in
- Front Shoulder Room: 68.85 in
- Front Hip Room: 65.48 in
- Exterior Dimensions
- Powertrain
- Engine
- Engine Order Code: L8T
- Engine Type: Gas V8
- Displacement: 6.6L/- TBD -
- Fuel System: Electronic Fuel Injection
- SAE Net Horsepower @ RPM: 401 @ 5200
- SAE Net Torque @ RPM: 464 @ 4000
- Engine Oil Cooler: Yes
- Engine Displacement Units: 6.6
- Engine Camshaft: OHV
- Engine Block Type: iron
- Engine Cylinder Count: 8
- Engine Valve Count: 2
- Transmission
- Drivetrain: Rear Wheel Drive
- Trans Order Code: MYD
- Trans Type: 6
- Trans Description Cont.: Automatic
- First Gear Ratio (:1): 4.03
- Second Gear Ratio (:1): 2.36
- Third Gear Ratio (:1): 1.53
- Fourth Gear Ratio (:1): 1.15
- Fifth Gear Ratio (:1): 0.85
- Sixth Gear Ratio (:1): 0.67
- Reverse Ratio (:1): 3.06
- Cooling System
- Total Cooling System Capacity: - TBD - qts
- Engine
Please Note: These technical specifications are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Safety
- Air bag - side
- Front Side Air Bag
- Rear Side Air Bag
- Front Head Air Bag
- Safety features
- Daytime Running Lights
- Traction Control
- Stability Control
- Air bag - frontal
- Driver Air Bag
- Passenger Air Bag
- Passenger Air Bag On/Off Switch
- Air bag - side
- Chassis
- Tires
- Tire Pressure Monitor
- Brakes
- ABS
- 4-Wheel Disc Brakes
- Wheels
- Steel Wheels
- Steering
- Power Steering
- Tires
- Exterior
- Tire - rear
- Tires - Rear All-Season
- Tire - front
- Tires - Front All-Season
- Tire - rear
- Powertrain
- Fuel
- Gasoline Fuel
- Engine
- 8 Cylinder Engine
- Drivetrain
- Rear Wheel Drive
- Transmission
- 6-Speed A/T
- A/T
- Transmission w/Dual Shift Mode
- Transmission Overdrive Switch
- Fuel
- Accessories
- Audio
- WiFi Hotspot
- Window
- Rear Defrost
- Convenience
- Intermittent Wipers
- Power Outlet
- Immobilizer
- Trip Computer
- Back-Up Camera
- Audio
Please Note: These options are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Factory Warranty
- Warranty Note: <<< Preliminary 2021 Warranty >>>
- Basic Years: 3
- Basic Miles/km: 36,000
- Drivetrain Years: 5
- Drivetrain Miles/km: 60,000
- Drivetrain Note: Qualified Fleet Purchases: 5 Years/100,000 Miles
- Corrosion Years: 3
- Corrosion Years: 6
- Corrosion Miles/km: 100,000
- Corrosion Miles/km: 36,000
- Roadside Assistance Years: 5
- Roadside Assistance Miles/km: 60,000
- Roadside Assistance Note: Qualified Fleet Purchases: 5 Years/100,000 Miles
- Maintenance Note: 1 Year/1 Visit
Please Note: This information is based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
